Application guide explains how high isolation and low leakage capabilities support high voltage measurements and insulation testing in EV applications
Pickering Electronics,a leading manufacturer of high-performance reed relays, has published an application guidefor engineers taking high voltage (HV) measurements and performing insulation testingin electric vehicles (EVs) and charging points. The guide, titled: ‘Reed Relays for Electric Vehicle and Charge Point Testing’, explains why high-isolation reed relays are ideal for use in instrumentation and test equipment intended for measuring high voltages andverifying the integrity of electrical insulation in EVs and charging points.
The electrification of drivetrains in electric vehicles (EVs)and hybrids (HEVs and PHEVs) is made possible by the presence of high voltage batteries, battery management systems (BMS), power inverters and powerful motors. All these highvoltage components are ‘floating’, meaning that none of their power terminals are earthed to chassis. Accordingly, all HV components and high current-carrying cables must be heavily insulated. The design and manufacture of EVs – as well as the associated charging points needed to power them – therefore require specialist equipment and procedures to ensure safety. And as more EVs enter service, their maintenance, repair and recovery will also require similar equipment and procedures.
“Electric vehicles and charging pointsare demandinghigh voltage environments forinstrumentation and test equipment,” said Robert King, Reed Relays Product Manager at Pickering Electronics. “Because of their compact size, high isolation and low leakage, reed relays are a strong fit for EV and chargepoint testing applications, where safety and measurement accuracy are both critical. Their mechanical contact path can switch AC or DC, while helping to minimise leakage that could otherwise affect insulation measurements.”
This guide explains that EV power cables and HV components are heavily insulated to protect against short circuiting against anything that is electrically connected to earth and for safety (since it is likely that anyone working on the vehicle will also be in contact with the chassis/earth). In addition to the need to measure high voltages (DC and AC), it is necessary to confirm the integrity of the insulation around HV components and cables.Also requiring high voltage and insulation tests – during product development and after they enter service – arethe charging points needed as the number of EVs joining our roads increases.
“There is, therefore, a need to develop instrumentation that can safely measure high voltages and perform insulation tests in charging points too – and that instrumentation will require switching,”added King. “Reed relays can offer leakage currents below 1 nA and stand-off voltages of several kV in compact packages. The reed switch contacts are hermetically sealed, helping protect them from contamination and oxidation compared with open electromechanical contacts.”
Reed relays offer a compelling solution because they are:
- Hermetically sealed, keeping dust and moisture away from the contacts
- Capable of high switching and stand-off voltages
- Extremely low leakage, supporting accurate sensing and monitoring
- Galvanically isolated, helping protect instrumentation electronics
- Fast, compact, and able to deliver millions or even billions of operations
Download this free EV & chargepoint testing application guideto learn from Pickering’s expert insights and recommendations on selecting the best relay technologies for your specifichigh voltage measurement and insulation testingneeds – and discover why reed relays provide the ideal switching technologiesfor EV and chargepoint applications.
