Nordic Semiconductor’s new nPM1100 PMIC for advanced wearable wireless products offers a higher efficiency-to-size ratio than any other PMIC solution
element14, an Avnet company and global distributor of electronic components, products and solutions,is now shipping Nordic Semiconductor’s latest power management chip, the nPM1100. The new Power Management IC (PMIC) offers a higher efficiency-to-size ratio than any other PMIC solution available in the market and a PCB area usage as low as 23mm².The ultra-small form-factor PMIC is ideal solution for space-constrained applications includingbattery charging and power delivery in hand-held, portable and advanced wearable wireless products, and connected medical devices.
Small wireless product designers are striving to increase battery life and add functionality without increasing the form factor. Adding battery capacity incurs a penalty in terms of physical volume, leaving power efficiency gains as the only way to achieve battery life and functionality improvements.The new nPM1100 PMIC from Nordic Semiconductor achieves this by combining a small form factor withtight integration and efficient power conversion, enabling designers to achieve longer battery life or more power capability without increasing the physical size of the electronic components.
The nPM1100 is a dedicated PMIC with a highly efficient dual-mode configurable buck regulator and integrated battery charger. It is designed as a complementary component to Nordic Semiconductor’s nRF52® Series and nRF53® Series of System-on-Chips (SoCs), which enable reliable power delivery and stable operation while maximising battery life through high efficiency and low quiescent currents. The nPM1100 can also be used as a generic PMIC device.
Key benefits of the new nPM1100 PMIC, now available for fast delivery from element14, include:
- Combined USB battery charging and power supply with a compact PCB implementation including passives and offering up to 92% power conversion efficiency
- The integrated battery charger is designed to charge lithium-ion and lithium-polymer batteries on a termination voltage selectable to 4.1 or 4.2 V, supporting cell chemistries with a nominal voltage of 3.6 and 3.7 Vrespectively.
- Automatic selection of three charging modes: automatic trickle, constant current and constant voltage.
- Compatibilitythat allows for charging batteries through USB with automatic port detection.
- 100% pin configurable with no software needed.
- Prolongs the battery life of any nRF52® or nRF53® Series SoC based application using a rechargeable battery.
- Provides ample current for both the SoC and any additional circuitry.
Simon Meadmore, Vice President of Product and Supplier Management, element14, says:“We are excited to see Nordic Semiconductor revolutionise the PMIC market with such a game changingproduct. The needfor innovative and compact professional wearable wireless devices and connected applications for medical use is growing exponentially. Connected medical devices for use in hospitals or patient homes offer many new opportunities. This new PMIC gives designers a new weapon for increasing power delivery and efficiency in an economic, ultra-low form factor package.”
Nordic Semiconductor plays a key role in the realisation of the wireless future and is passionately committed to ultra-low power wireless technology. Nordic Semiconductor was established in 1983 and has more than 1300 employees across the globe. The Norwegian fabless semiconductor company specialisesin wireless communication technology that powers the Internet of Things (IoT). Nordic Semiconductor is a market leader with award-winning Bluetooth Low Energy solutions that are pioneeringnew ultra-low power wireless applications.
element14 offers an extensive range of products in its comprehensive semiconductor portfolio to support design engineers. Customers also have free access to online resources, datasheets, application notes, videos, webinars and 24/5 technical support.
Nordic Semiconductor’s new nPM1100 PMIC is available for fast delivery from Farnell in EMEA, Newark in North America and element14 in APAC.
