Power Integrations Launches Single-Board Plug-and-Play Gate Drivers


NTCtemperature readoutimproves accuracy, increasing reliability and module utilization by up to 30 percent

Power Integrations (NASDAQ: POWI), the leader in gatedriver technology for medium- and high-voltage inverter applications,today announced the launch of the SCALE-iFlex™ XLTfamily of dual-channel plug-and-play gate drivers for operation of single LV100 (Mitsubishi), XHP™2 (Infineon), HPnC (Fuji Electric) and equivalent semiconductor modules up to 2300 V blocking voltageforwind, energy storage and solar renewable energy installations.This single-board driver enables active thermal management of inverter modulesfor improvedsystem utilization and reducesthe bill-of-material count for increased reliability.

Thorsten Schmidt, product marketing manager at Power Integrations commented: “It’s a real challenge to build a single-board gate driver for these ‘new dual’ style IGBT modules. Our compact new SCALE-iFlex XLT gate drivers fit inside the outline of the module, allowing the drivers to be mounted on the module, which givesconverter system designers a high degree of mechanical design freedom.”

SCALE-iFlex XLTdual-channel gate driversfeature Negative Temperature Coefficient (NTC) data reporting – an isolated temperature measurement of the power module – which allowsaccurate thermal management of converter systems. This enables system designers to optimize thermaldesign and obtain a 25 to30 percentconverter power increase from the same hardware. The isolated NTC readout also reduces hardware complexity, eliminating multiple cables, connectors and additional isolation barrier crossing circuits.

The new gate drivers employ Power Integrations’ SCALE-2 chip set which minimizes component count, enhancing reliability. The gate driver boardalso protects the power switches in the event of a short-circuit.


SCALE-iFlex XLTplug-and-play gatedrivers are available for sampling now. Please contact your local sales representative for pricing.

For more information, please visitwww.power.com/scale-iflex-xlt.
